Engine Specifications
Make/Model........Cummins 6CT 8.3, 150HP
Fuel......................Diesel
No
of cylinders......6
Displacement.........167 cubic in. 2.732
Max
Speed............2,800 RPM
Power rating .........170 HP
Cooling medium.....Radiator
Air
Cleaner............Dry Element
Oil
Filter.................Spin on type
Cold weather aid.....Starting glow plug
Fuel tank capacity....50 Gallons
Fuel cap...................w/Lockable
latch
Fuel level..................Electric
gauge
Electric system..........12 Volt 100
AMP
SAFETY DEVICES
Backup alarm
Amber strobe
Audible horn
Safety "deadman Seat"
Seat belts Headlights
2 - Forward
2
-Reverse
|
 |
General Specifications
Load capacity..........150,000 to 400,000 lbs.
Level drawbar pull....30,000 lbs.
Turning radius...........18' -6''
Maximum speed.......13.5 MPH
Weight ....................53,000 lbs.
Length .....................218''
Height .....................123''
Width .....................128''
Chassis....................2½'' Steel Plate
Body ......................2½'' Steel Plate
Hitch ......................Pin
Drive whl. tires (4)...Foam
Filled
Steer Tires (2).........Foam
Filled
Transmission...........Clark 36,000 -3
speed
|
|
|
